TP-Link TL-SG1005LP network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Sponsored This site contains affiliate links for which we may receive compensation. More information
Sponsored TP-Link PoE Switch 5-Port Gigabit, 4 PoE+ ports up to 30 W for each PoE port and
83.57 USD
Price updated on: 11-05-2026 04:04:06
83.57 USD
Price updated on: 11-05-2026 04:04:06 | Identifiers | |
|---|---|
| MPN | TP-LINK TL-SG1005LP |
| Dimensions / Weight | |
| Key Features | |
|
AC input voltage The range of alternating current voltage that the product accepts from its power source, expressed in volts (V). It indicates the minimum and maximum supply voltages compatible with the device across different regions.
|
100 - 240 V |
|
Cable types supported A list of the cable categories or standards that a product can use, such as Cat5e, Cat6, Cat6a, Cat7, Fiber, HDMI, USB, etc. The values are separated by commas and represent the types of cables compatible with the device.
|
Cat3,Cat4,Cat5,Cat5e,Cat6 |
|
Certification A list of official certifications or compliance marks that the product has received from regulatory bodies, safety organizations, or industry standards groups. Each entry represents a distinct certification such as CE, FCC, RoHS, UL, or WEEE, and may include additional details like version numbers or specific test reports.
|
FCC, CE, RoHS |
|
Colour The colour or combination of colours that a product is available in, expressed as common names such as "Black", "Silver" or comma‑separated lists like "Black, White". It indicates the visual appearance of the item for consumers.
|
Black |
|
Copper ethernet cabling technology A comma‑separated list of the copper Ethernet standards supported by a device, such as 10BASE‑T, 100BASE‑TX, or 1000BASE‑T. Each entry indicates a specific speed and physical specification that the product can transmit over its RJ‑45 ports.
|
10BASE-T,100BASE-TX,1000BASE-T |
|
Fanless Indicates whether the product operates without a fan for cooling or ventilation.
|
Yes |
|
Form factor Specifies the physical configuration or design of a product, such as ATX, Micro‑ATX, Mini‑ITX, tower, case with cover, etc. It describes how the device is built and what mounting or expansion options it supports.
|
Switch |
|
Harmonized System HS code The Harmonized System (HS) code is a standardized numerical identifier used internationally to classify traded goods. It consists of up to six digits, where each pair of digits represents progressively more specific product categories. The HS code facilitates customs duties, trade statistics, and regulatory compliance by providing a common language for describing products across borders.
|
85176990 |
|
Jumbo frames The largest Ethernet frame size in bytes that the device can transmit or receive without fragmentation. This value determines the maximum payload that can be sent in a single network packet, which can improve throughput for high‑bandwidth applications.
|
16000 |
|
Maximum power consumption The highest electrical power that a device can draw or consume during operation, expressed in watts (W). It represents the peak energy usage of the product and is useful for estimating maximum power requirements, comparing efficiency across similar devices, and ensuring compatibility with power supplies.
|
47.5 W |
| Networking standards | IEEE 802.1p,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
|
Operating relative humidity The range of relative humidity (in percentage) within which the product is designed to operate reliably. Values are expressed as a minimum–maximum interval such as "20 - 80 %" and indicate the acceptable environmental moisture level for optimal performance.
|
10 - 90 % |
|
Power adaptor type The classification of the power adaptor used with a device, indicating whether it is external or internal, its electrical interface (AC, DC, USB‑Charging, etc.), and any specific form such as integrated or travel adapters. This attribute helps buyers understand how the device receives power and what kind of connector or cable is required.
|
External |
| Power cord | Yes |
|
Power over Ethernet plus PoE+ ports quantity Indicates the total count of Power over Ethernet Plus (PoE+) output ports available on a networking device. The value is an integer representing how many ports can supply PoE+ power to connected equipment, such as network cameras or access points.
|
4 |
|
Protocols Supported A list of network communication protocols that a device can use or support, such as TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, and various wireless standards. Each protocol is represented by its standard name and may be separated by commas or slashes in the source data.
|
AUTO NegotiationAUTO MDI/MDIX |
|
RJ-45 ethernet ports type Indica los estándares o velocidades que soportan los puertos RJ‑45 presentes en el producto, como Fast Ethernet (10/100 Mbps), Gigabit Ethernet (1 Gbps) o 10 Gigabit Ethernet. Cada valor describe una capacidad específica del conector y permite comparar la compatibilidad de red entre dispositivos.
|
1000 ) |
|
Storage relative humidity The range of relative humidity (expressed as a percentage) within which the storage device is designed to operate reliably. Values are given as a minimum–maximum interval such as "10 - 90 %" and indicate the acceptable environmental moisture level for optimal performance.
|
5 - 90 % |
|
Storage temperature The range of temperatures in which a device can safely operate without risk of damage or performance degradation. Values are expressed in degrees Celsius (°C) and may represent a single temperature, a minimum–maximum interval, or an average operating point.
|
-40 - 70 °C |
|
Switch type The classification of a network switch based on its management capabilities, such as Managed or Unmanaged. This attribute indicates whether the device can be configured and monitored remotely (Managed) or operates with fixed settings without remote configuration (Unmanaged). It helps users choose a switch that matches their networking expertise and control requirements.
|
Unmanaged |
|
Total Power over Ethernet PoE budget The maximum electrical power that a network device can supply to connected Power over Ethernet (PoE) devices, expressed in watts (W). It represents the total PoE budget available for powering attached equipment such as switches, access points, or cameras.
|
40 W |
|
Warranty The length of time for which the manufacturer guarantees that the product will be free from defects in materials and workmanship, typically expressed in years or months.
|
1 Year |

TP-Link is a brand of networking products that was founded in 1996. The company is headquartered in China, and manufactures a wide range of networking products, including routers, switches, and adapters. TP-Link has a large global presence, and is one of the most popular networking brands in the world.
